MAX Tech Specs
Size and Weight
MAX L
Machine Dimensions:
1060 x 760 x 600 mm
41.8 x 30.0 x 21.7 in
Work Area:
850 x 500 x 130 mm
33.5 x 19.7 x 5.2 in
Weight:
100kg
MAX XL
Machine Dimensions:
1260 x 1260 x 600 mm
49.6 x 49.6 x 23.7 in
Work Area:
1000 x 1000 x 130 mm
39.4 x 39.4 x 5.2 in
Weight:
125 kg
Milling Materials
Aluminum
Wood
Plastics
Soft Metals
Spindle
Type: AMB 1050 FME-1
Power: 1050 W
Speed: 5000-25000/Min
Collet Size: Standard-8 mm
Hardware
Machine-Type: Assembly Kit
Assembly Time: 4-5 hours
Machine Table: Aluminum T Slot Table
Ball Screws: Custom CNC ONE Backlash-free Ball Screws
No-Load Repeatability: +/- 0.01mm | +/- 0.0004 in
Linear Rails: HGR 20 , 4 Linearwaggons on each axis
Motors: 4x 180w Closed Loop Servos
X and Y Axis: 6060 profile on Y Axis, 9060 profile on X Axis
XYZ Endstops: 2x Inductive Endstops on Y-Axis, 1x on X- and Z-Axis
XYZ Max Speed: Max Limit: 10000 mm/min | Preset Limit 6000 mm/min
Control and Software
Touchscreen:
13.3" Full HD Capacitive Touchscreen
Machine Control:
Linux CNC with custom CNC ONE Interface
CAD/CAM Software:
Fusion 360 recommended
Compatible with other softwares
Power
Power Input:
230V
Power Consumption:
Max. 800W (Without Spindle)
Outputs:
2x USB-A Devices for Touch Screen and USB-Stick
1x HDMI Output
1x Ethernet Output
1x 230V Output with 10A fuse (not switched)
5x General Purpose switched 24V Outputs
1x 0-10V Spindle speed output
Inputs:
Emergency Stop
Z-Probe
XYZ-Probe
